5 In 1 Mini Internal Passive External Marinated RTK GNSS LTE GSM WiFi 4G MIMO Car GPS Combo Antenna

Product Categories

Shenzhen Yetnorson Technology Co., Ltd/Yetnorson Antenna Co., Limited

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

5 In 1 Mini Internal Passive External Marinated RTK GNSS LTE GSM WiFi 4G MIMO Car GPS Combo Antenna

Name: 5 In 1 Mini Internal Passive External Marinated RTK GNSS LTE GSM WiFi 4G MIMO Car GPS Combo Antenna
Brand: yetnorson
Price: 2.87 USD

Quality 5 In 1 Mini Internal Passive External Marinated RTK GNSS LTE GSM WiFi 4G MIMO Car GPS Combo Antenna wholesale

Model Number : yxn gps 2

Type : GPS/GNSS Antenna

Place of Origin : Guangdong, China

Brand Name : yetnorson

Center Frequency (MHz) : 1575.42~1610MHz

Gain(dBi) : 28dBi

V.S.W.R : 2:01

Connector : SMA/Fakry/USB

Cable : RG174/1~5 Meters

Impedance : 50ohm

Weight : 60 gram

Size : 35x30x15mm

Supported Positioning Signal Bands : GPS (1575.42MHZ) BD (1561MHZ) GLONASS (1601MHZ)

Radome : ABS+PC

Packaging Details : 1pcs antenna/PE bag. 200pcs/CTN for 5 In 1 mini internal Passive External Marinated Rtk Gnss Lte Gsm Wifi 4g MIMO Car Gps Combo Antenna

Port : Shenzhen

Supply Ability : 20000 Piece/Pieces per Day GPS Antenna Receiver Repeater Signal

MOQ : 2 pieces

Price : $2.87/pieces 2-99 pieces

Contact Now

5 In 1 Mini Internal Passive External Marinated RTK GNSS LTE GSM WiFi 4G MIMO Car GPS Combo Antenna

Specification

GPS&GLONASS Antenna	Frequency Range	1575.42~1610MHz
		Polarization	RHCP
		Impedance	50Ω
		Dimension	1038mm
		Gain	28±2dB
		Noise Figure	≤1.5dB
		Supply Voltage	3~5V DC
		Current Consumption	＜15mA
		V.S.W.R	＜2.0
LTE Antenna MIMO	Frequency Range	698~960MHz/1710~2690MHz
		V.S.W.R	＜3.0
		Polarization	Linear
		Gain	2-3dBi
		Impedance	50Ω
WIFI Antenna MIMO	Frequency Range	2400~2483.5MHz/4900~5825MHz
		V.S.W.R	＜2
		Polarization	Linear
		Gain	2-3dBi
		Impedance	50Ω

Hot selling product (88% of people buy it together)

Company Profile

Yetnorson Antenna Co., Limited is an antenna factory with 12 years of experience in manufacturing antennas. It is a national high-tech enterprise and a 5A-level credit enterprise.

Our factory covers an area of 12,000 square meters, has two workshops and 8 production lines and has a production staff of 352 people, to ensure fast and timely delivery; there are 32 professional business teams to guarantee you professional product services; there are 8 professional engineering teams and tens of millions of testing and production equipment; has 36 antenna patents, all All products have passed ISO/FCC/CE/ROHS certification!

We can customize packaging, patterns and free logo printing, your goods can track the progress at any time, welcome to visit our factory or video tour at any time!

Mechanical Equipment

Storehouse

Certifications

FAQ

Q: I want to increase the popularity of our products, can I print the logo on the product?

A: Of course, no matter how many MOQs,we can print the logo for free.

Q: I want to know the production progress of my goods .
A: We will take photos or videos to tell you the progress of your goods at every stage from production to shipment.

Q: Can we customize it?
A: You can customize the packaging, pattern, color, cable length and other needs of any customer and we will try our best to meet it.

5 In 1 Mini Internal Passive External Marinated RTK GNSS LTE GSM WiFi 4G MIMO Car GPS Combo Antenna Images
